Get the unmatched reliability and performance of our Silicon Steel Strip Material, designed for exceptional magnetic properties, minimal core loss, and superior energy efficiency. Engineered from the finest raw materials, this steel strip ensures consistent performance in a wide range of electrical and industrial applications from transformers and motors to generators and inductors.
High Magnetic Permeability: Provides excellent magnetic flux density, ensuring reduced energy consumption and higher operational efficiency.
Low Core Loss:
Minimizes energy loss during magnetization, enhancing the overall performance and longevity of your equipment.
Superior Surface Quality:
Uniform thickness and smooth surface finish ensure easy processing and precise manufacturing outcomes.
Excellent Mechanical Strength:
Delivers outstanding durability and resistance to fatigue, even under high-stress conditions.
Temperature Stability:
Maintains magnetic properties and performance consistency across varying temperature ranges.
Custom Sizes and Grades:
Available in both grain-oriented (GO) and non-grain-oriented (NGO) types, customizable to meet your specific technical requirements.
Our Silicon Steel Strip Material is widely used in industries where energy efficiency and electromagnetic performance are crucial, such as:
| Property | Description |
| Material Type | Grain-Oriented (GO) / Non-Grain-Oriented (NGO) |
| Thickness Range | 0.18 mm – 0.50 mm |
| Width Range | Up to 1000 mm |
| Surface Coating | Insulation coating (C2/C5 options) |
| Magnetic Flux Density (B50) | ≥ 1.70 T |
| Core Loss (W/kg @ 1.5T, 50Hz) | ≤ 1.3 W/kg |
| Tensile Strength | 350–500 MPa |
| Standard | ASTM A876, IEC 60404, GB/T 2521 |
Each silicon steel strip is securely packaged to prevent oxidation and physical damage during transit. We offer flexible packaging options, coil form, sheet form, or custom-cut strips, based on your production needs. Global shipping and expedited delivery are available upon request.
Need a specific size, coating, or grade? Our engineering team can custom-produce silicon steel strips tailored to your magnetic and mechanical performance requirements.
